15kV Zırhlı Tek Damarlı AL İletkenli Isı Büzüşmeli Ek Muf

Resimi Büyütün

Anma Voltajı
Rated Voltage		 Kod/
Code

Kablo Kesiti

Cross. Sec.Of Cable
(mm²)

 D (mm) L1 (mm) L2 (mm) L3 (mm) Zırhlı Kablo Çapı
Diameter of Armoured Cable
( mm ² )
8.7 - 15kV ZIB15-125 1x25+16 57 350 700 800 30
ZIB15-135 1x35+16 57 350 700 800 31
ZIB15-150 1x50+16 57 350 700 800 32
ZIB15-170 1x70+16 77 350 700 800 34
ZIB15-195 1x95+16 77 350 700 800 37
ZIB15-1120 1x120+16 77 350 700 800 39
ZIB15-1150 1x150+25 77 350 700 800 40
ZIB15-1185 1x185+25 82 350 700 800 42
ZIB15-1240 1x240+25 82 350 700 800 45
ZIB15-1300 1x300+25 85 350 700 800 48
ZIB15-1400 1x400+35 88 350 700 800 52
ZIB15-1500 1x500+35 93 350 700 800 55
ZIB15-1630 1x630+35 98 350 700 800 59
